EXTREME 32 HEAVY DUTY SHADE FABRIC

Shade fabric that stands up to the toughest of
New Zealand’s ‘Roaring Forties’ weather conditions.

Extreme 32 (E32) is a heavy-duty shade cloth specifically designed for large scale shade sail and structure installations that require high strength and stability. Due to its monofilament and tape construction Extreme 32 not only performs excellently in harsh conditions but also provides impressive UVR protection (up to 95.8%).

Extreme 32

With high strength and stability properties Extreme 32 is perfectly suited to large high-tension shade sails or unique architectural shade structures.

E32 is ideal in situations where shade is needed year-round and in more exposed areas such as:

  • Wind tunnels created between buildings
  • Beach front properties
  • Cliff and building tops
  • Windy plains
  • Snow regions

Benefits

  • Extreme Strength
    EXTREME STRENGTH
    (DESIGNED FOR LARGE SPANS)
  • High UV-R Protection
    HIGH UV-R PROTECTION
    (UP TO 95.8%)
  • High Tear Resistance
    HIGH TEAR RESISTANCE
  • Resilient Dimensional Stability
    RESILIENT DIMENSIONAL STABILITY
  • null
    100% RECYCLABLE
  • Easy Care and Maintenance
    EASY CARE & MAINTENANCE
  • Fire Rated Fabric
    FIRE RATED FABRIC AS-1530.3
  • Enduring Durability and Longevity
    ENDURING DURABILITY & LONGEVITY
  • Great Heat and Glare Reduction
    GREAT HEAT & GLARE REDUCTION
  • Hail Resistance
    HAIL RESISTANCE
  • 15 Year Warranty
    BACKED BY A 15 YEAR WARRANTY

Inspiration

Colour Range - 14 Colours

Quartz
UVR Block: 89.5%
Shade: 78.4%

Cinnamon
UVR Block: 91.4%
Shade: 89.4%

Hazel
UVR Block: 95.8%
Shade: 94.4%

Desert Sand
UVR Block: 92.4%
Shade: 91.2%

Silver
UVR Block: 91.5%
Shade: 91.2%

Charcoal
UVR Block: 95.3%
Shade: 94.7%

Black
UVR Block: 95.7%
Shade: 95.3%

Terracotta
UVR Block: 92.7%
Shade: 92.7%

Rainforest
UVR Block: 93.7%
Shade: 90.7%

Navy Blue
UVR Block: 95.8%
Shade: 94.4%

Royal Blue
UVR Block: 91.7%
Shade: 86.1%

Sunset Red
UVR Block: 93%
Shade: 83.7%

Zesty Lime
UVR Block: 91.1%
Shade: 84.5%

Electric Purple
UVR Block: 91.9%
Shade: 88.4%

Product Tech Specs

Fabric Width 3m
Fabric Weight 320 g/m2
Roll length 33m
UVR Block & Shade Protection* See individual colours above or refer to swatch
Flammability Index** 19
Breaking Force (Warp) 717 N/50mm
Breaking Force (Weft) 1721 N/50mm
Elongation at Break (Warp) 44.70%
Elongation at Break (Weft) 54.90%
Tear Resistance (Warp) 179 N
Tear Resistance (Weft) 243 N
Bursting Pressure 3400 kPa
Bursting Force 1970 N
UV Warranty 15 years
Tension Memory Fully stentored – despite its weight, E32 will retain its excellent tensioned look for longer (less than 2.5% stretch)

* Independently tested to AS 4174-1994 and AS/NZ 4299-1996
** Independently tested to AS/NZ 1530.2-1993

MARKETING & PRODUCT SUPPORT

Fabric Swatch

Showcasing Extreme 32’s range of designer colours with UV-R Block and Shade statistical data.

Request a Swatch

SUPPORTIVE LEAD TIMES

Your customers are demanding tight timeframes, and we get it. That’s why we operate a Just-in-Time (JIT) dispatch policy – not too early, not too late.

  • All colours stocked in NZ
  • We can even weld several drops together to save you time and hassle

OVERVIEW

Extreme 32 fabric is manufactured using the highest quality raw materials available to ensure that this shade cloth can stand up to New Zealand’s unforgiving climate and environment.

Rainbow Shade’s Extreme 32 shade cloth has been rigorously tested against the sun and elements, so much so that we offer a 10 year warranty on the fabric against UV breakdown.

To view Extreme 32 shade cloth’s test results for UVR block, strength, hail testing, fire testing and more browse our downloads section above.

For more detailed information and technical specifications on Extreme 32 contact our friendly team on 0508 665 665.
